Airtac HGS Micro Precision Slide Table Cylinder HGS12X20SJ
2、High-strength alloy steel quick-connect pins ensure superior wear resistance and extended service life.
3、Optional stroke adjustment mechanism compatible with direct replacement of hydraulic actuators.
4、Precision-ground rails deliver exceptional linear accuracy (±0.03mm) and non-rotation stability.
5、Comprehensive series configuration with high-strength optional accessories for customized solutions.
6、Integrated positioning holes and adjustment grooves optimize installation precision while maintaining positioning consistency during repeated disassembly.
（For custom stroke requirements exceeding standard specifications, please consult our engineering team）
Category: Precision Slide Cylinder | Brand: AIRTAC | Series: HGS
AirTAC HGS Micro Precision Slide Cylinder HGS12X20SJ Specifications
- Model: HGS12X20SJ (Series: HGS Compact Slide Cylinder)
- Structure: Double-rail type with integrated linear guide
- Bore size: Ø12mm
- Stroke: 20mm (Standard stroke range: 10-300mm)
- Operating pressure: 0.05-0.7 MPa
- Temperature range: -10℃ to 80℃
- Cushioning: Adjustable rubber cushion (both ends)
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s
- Load capacity:
- Radial moment: 1.2N·m
- Lateral moment: 1.5N·m
- Vertical load: 25N
- Mounting: Horizontal/vertical (axial load only)
- Port size: M5x0.8 (Dual ports at both ends)
- Seal material: NBR + Special polyurethane
- Protection rating: IP54 (Dust-proof & splash-resistant)
- Weight: 280g ±5g
- Dimensions:
- Length: 133mm (including rod)
- Width: 34mm
- Height: 28mm
Ultra-compact slide cylinder combining pneumatic actuation with precision linear guidance, featuring dual-axis stabilization for vibration-free operation. The hardened stainless steel shaft and aluminum alloy body ensure wear resistance in high-cycle applications (up to 5 million cycles). Includes auto-lubrication design with built-in oil retention grooves.
- Micro-pipetting systems in medical analyzers
- Lens positioning in optical inspection equipment
- PCB component insertion machines
- Precision dotting mechanisms for semiconductor packaging
- Automated microscope stage controls
Installation guidelines:
Maintain parallelism within 0.05mm/m during mounting. Use clean dry air (ISO 8573-1 class 2.4.2) with 1-5μm filter. Lubricate with ISO VG32 turbine oil if operating below 0.1MPa. Avoid side impact forces exceeding 10N.
| Property | Property Value |
|---|---|
| sku | HGS12X20SJ |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
