Airtac HSV Hand Slide Valve HSV06SF
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
AirTAC HSV06SF Manual Slide Valve Technical Details
- Model: HSV06SF
- Type: 3-position closed center, 5-way manual slide valve
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Manual operation: Lever-type mechanical override
- Flow capacity: 850 L/min (at 0.5 MPa)
- Weight: 420g ±5% (including accessories)
- Dimensions: 68mm(L) × 42mm(W) × 85mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Temperature range: -10℃ to 80℃ (FKM seals)
- Response time: ≤50ms (manual actuation)
- Port thread depth: 12mm (minimum engagement)
- Mounting: Direct panel mounting with M5 screws
Industrial-grade manual override valve featuring positive center position locking and visual position indicator. The HSV06SF combines mechanical precision with IP67 environmental protection, designed for emergency operation or system debugging in harsh conditions. Features double-seal construction with anti-vibration design for stable position retention.
- Production line emergency stop systems
- Hydraulic press safety override controls
- Plastic injection molding machine maintenance
- Food processing equipment manual mode operation
- Automated warehouse conveyor troubleshooting
Maintenance advisory:
Lubricate sliding surfaces with ISO VG32 hydraulic oil every 50,000 cycles.
Avoid lateral force exceeding 15N during lever operation. For vertical installation,
ensure exhaust ports face downward to prevent debris accumulation.
| Property | Property Value |
|---|---|
| sku | HSV06SF |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
