Airtac HSV Hand Slide Valve HSV06SS
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
AirTAC HSV06SS Manual Slide Valve Technical Details
- Model: HSV06SS (Standard Configuration)
- Type: 3-position, 4-way manual directional control valve
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.1–0.8 MPa
- Max flow capacity: 750 L/min (ANR)
- Valve body material: Aluminum alloy (hard anodized)
- Spool seal: HNBR rubber (high nitrile)
- Handle type: Lockable lever with ergonomic grip
- Center position function: Closed center/exhaust center options
- Operating temperature: -20℃ to 80℃
- Mounting style: Panel mount with M5 screw holes
- Weight: 185g ±5g (without accessories)
- Dimensions: 52mm(L) × 34mm(W) × 43mm(H)
- Port thread depth: 10mm (minimum engagement)
- Actuation force: ≤3.5N (lever operation)
Industrial-grade manual valve featuring positive center detent and visual position indicator. The HSV06SS combines smooth operation with IP54-rated dust/water resistance. Features dual wiper seals for contamination prevention and hardened steel shaft for extended cycle life (500,000+ operations). Compatible with ISO 15407-1 standard pneumatic systems.
- Emergency stop circuits in production lines
- Manual override in automated machinery
- Training equipment for pneumatic system education
- Mobile hydraulic/pneumatic hybrid systems
- Maintenance bypass control in HVAC systems
Installation Guidelines:
Use thread sealant on port connections (NOT Teflon tape). Maintain minimum 15mm
clearance around lever arc. For horizontal mounting, orient exhaust ports downward
to prevent debris accumulation. Lubricate spool monthly with ISO VG32-grade oil.
| Property | Property Value |
|---|---|
| sku | HSV06SS |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
