Airtac HSV Hand Slide Valve HSV08FF
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
AirTAC HSV Hand Slide Valve HSV08FF Technical Details
- Model: HSV08FF (Manual Override Type)
- Valve Type: 3-position, 4-way closed center
- Port Configuration: P, A, B, T
- Port Size: 1/4" NPT (G1/8 optional)
- Operating Pressure: 0.05–0.7 MPa (7–100 PSI)
- Max Flow Rate: 450 L/min (Cv=0.48)
- Manual Operation Force: ≤30N
- Seal Material: HNBR (Hydrogenated Nitrile)
- Body Material: Anodized aluminum alloy
- Temperature Range: -10℃ to 80℃ (14°F to 176°F)
- Weight: 215g ±5g
- Dimensions: 48mm(W) × 35mm(H) × 82mm(L)
- Mounting: ISO 4401-03-02-0-94 standard
- Protection Class: IP54 (dust/water resistant)
The HSV08FF features a unique dual-action ergonomic lever with positive tactile feedback, designed for precise manual control in emergency override situations. Its chrome-plated spool ensures smooth operation even after prolonged storage. The valve incorporates a debris-resistant internal structure with self-cleaning seals, making it ideal for harsh environments.
- Emergency stop systems in plastic injection molding machines
- Manual mode override for automated assembly lines
- Material handling equipment maintenance bypass
- Hydraulic/pneumatic hybrid control systems
- Test bench fluid circuit configuration
Installation Best Practice:
Lubricate the slide mechanism with ISO VG32 hydraulic oil before initial use.
Avoid lateral side-load forces on the manual lever - maximum permissible
moment is 0.5Nm. For vertical mounting, install with ports facing downward
to prevent particle accumulation.
| Property | Property Value |
|---|---|
| sku | HSV08FF |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
