Airtac HSV Hand Slide Valve HSV08SS
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
AirTAC HSV Manual Slide Valve HSV08SS Technical Details
- Model: HSV08SS
- Type: 3-position manual slide valve (open-center)
- Port size: PT1/4 (G1/8 optional)
- Operating pressure: 0.05–1.0 MPa
- Flow capacity: 650 L/min (ANR)
- Actuation force: ≤25N
- Body material: Anodized aluminum alloy
- Seal material: HNBR (high-temp nitrile)
- Temperature range: -10℃ to 120℃
- Weight: 350g ±5%
- Dimensions: 58mm(L) × 34mm(W) × 42mm(H)
- Port thread depth: 10mm
- Operating cycles: ≥500,000
- Mounting options: Panel/surface mount with M4 screws
Manual override valve with tactile position feedback, featuring zero-leakage design for precise flow control. The ergonomic thumb lever allows single-handed operation with positive detent positions. Corrosion-resistant construction with integrated dust wipers prevents internal contamination.
- Emergency bypass in automated production lines
- Maintenance override for pneumatic test benches
- Manual control in material handling systems
- Safety isolation in paint spray booths
- Educational pneumatic training rigs
Operation guidance:
Apply firm lateral pressure when switching positions - partial engagement may cause
air leakage. Lubricate slide mechanism with ISO VG32 pneumatic oil every 6 months.
- Port rotation: 0°, 90°, 180° orientations available
- Lever extensions: Optional 50mm/100mm handles
- Position indicators: Color-coded flags (red/yellow/green)
| Property | Property Value |
|---|---|
| sku | HSV08SS |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
