Airtac HSV Hand Slide Valve HSV15
$19.97
Regular price
$27.47
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
HSV15
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Diversified internal/external threaded connections for compatibility with various piping systems;
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
Operation guidance:
Apply even lateral force on the red manual actuator. Lubricate slide rail monthly with ISO VG32 hydraulic oil. Avoid axial impacts exceeding 50N.
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
AirTAC HSV15 Manual Slide Valve Technical Details
- Model: HSV15
- Type: 3-position (Center Closed) / 5-port manual slide valve
- Port configuration: P, A, B, R1, R2
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa
- Max flow rate: 750 L/min (ANR)
- Operating temperature: -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Manual override force: ≤30N
- Weight: 235g ±5%
- Dimensions: 58mm(L) × 36mm(W) × 27mm(H)
- Mounting: Sub-base compatible (ISO G1/4 standard)
Mechanical manual override valve with positive center position lock, designed for emergency operation or system debugging. Features low operating torque and wear-resistant slide mechanism with dust-resistant metal wipers. Compatible with ISO 15407-1 standard sub-bases.
Typical Applications:
- Production line emergency stop systems
- Pneumatic cylinder manual positioning
- Equipment maintenance bypass control
- Educational training rigs
- Automated warehouse shuttle controls
Operation guidance:
Apply even lateral force on the red manual actuator. Lubricate slide rail monthly with ISO VG32 hydraulic oil. Avoid axial impacts exceeding 50N.
| Property | Property Value |
|---|---|
| sku | HSV15 |
| Position | 3-Port 2-Position |
| Port Size | PT 1/2 |
