Airtac HSV Hand Slide Valve HSV25
2、Precision-engineered directional switching mechanism with smooth sliding operation and ergonomic tactile feedback;
3、Optimized flow path design ensuring maximum Cv value;
4、Hard-anodized spool surface and anodized aluminum alloy body provide exceptional wear resistance and permanent anti-corrosion properties.
Category: Manual Slide Valve , Brand: AIRTAC , Series: HSV
AirTAC HSV25 Manual Slide Valve Technical Details
- Model: HSV25
- Type: 3-position (All ports blocked in center), 5-way manual override valve
- Port size: PT1/4 (G1/8 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 750 L/min (ANR)
- Actuation type: Mechanical lever lock mechanism
- Weight: 300g ±5% (without accessories)
- Dimensions: 65mm(L) × 42mm(W) × 75mm(H)
- Body material: Anodized aluminum alloy
- Seal material: NBR/FKM optional
- Temperature range: -20℃ to 80℃ (NBR seals) / -10℃ to 150℃ (FKM seals)
- Port thread standard: ISO 228/1 (BSPP)
- Mounting options: Panel mount with M4 screws or DIN rail adapter
Industrial-grade manual override valve designed for emergency operation and system debugging. Features positive-center shutoff position with tactile lever feedback, corrosion-resistant construction with hard coat anodization. Requires 5-40μm filtered compressed air. Meets ISO 6150-1 standards for pneumatic directional valves.
- Production line emergency stop systems
- Pneumatic cylinder manual positioning during maintenance
- Automated machinery safety lockout procedures
- Material handling system troubleshooting
- Hydraulic system pilot control (air-operated oil valves)
Operation guidance:
Apply 20-30N force perpendicular to lever axis for smooth shifting.
Lubricate sliding surfaces with ISO VG32 pneumatic oil annually.
Avoid side-loading during actuation to prevent internal guide pin wear.
| Property | Property Value |
|---|---|
| sku | HSV25 |
| Position | 3-Port 2-Position |
| Port Size | PT 1/8 |
