Airtac MIC Cushioned Mini Cylinder MIC16X100SCM
The AirTAC Airtac MIC Cushioned Mini Cylinder MIC16X100SCM is a genuine double acting + cushion round-body mini air cylinder with a Ø16mm bore and 100mm stroke, M5×0.8 air ports and a stainless-steel barrel and rod for mildly corrosive environments. Its ISO 6432 mounting interface makes it a compact drop-in for standard mini-cylinder fixtures.
- BoreØ16 mm
- Stroke100 mm
- Port sizeM5×0.8
- Acting typeDouble acting + cushion
- Rod threadM6×1.0
- CushionVariable air cushion, both ends
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac MIC Cushioned Mini Cylinder MIC16X100SCM
Dial in end-of-stroke deceleration with the AirTAC MIC16X100SCM, a double-acting round-body mini cylinder built around a needle-set variable air cushion at both ends. The stainless-steel barrel and Ø6 mm piston rod resist mild corrosion and washdown, while the 100 mm stroke drops directly into standard ISO 6432 mini-cylinder mounting interfaces. An M5×0.8 port feeds the 16 mm bore, which generates 100.5 N of push force at 0.5 MPa.
For sizing, the 0.5 MPa push figure translates to a safe working load of roughly 60 N, or a vertical lift of about 5.1 kg with a 2:1 margin. The built-in piston magnet (-S suffix) supports CMSG, DMSG and EMSG reed or electronic switches, and the CM round rear cover provides a clean back-end port orientation. The cushion only decelerates the load near the stroke end; it is not a brake.
Airtac MIC Cushioned Mini Cylinder MIC16X100SCM Technical Specifications
| Model | Airtac MIC Cushioned Mini Cylinder MIC16X100SCM |
|---|---|
| Series | MIC ISO 6432 mini cylinder |
| Bore size | Ø16 mm |
| Stroke | 100 mm |
| Acting type | Double acting + cushion |
| Port size | M5×0.8 |
| Rod thread | M6×1.0 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Variable air cushion, both ends |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MI/MIC (ISO 6432) datasheet. Barrel & rod: stainless steel (round-body, riveted construction). Thread options: PT (blank) / G.
Theoretical Output Force (Ø16mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 101 N | 86 N |
| 0.7 MPa | 141 N | 121 N |
| Max (@1.0 MPa) | 21 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac MIC Cushioned Mini Cylinder MIC16X100SCM
| MIC | ISO 6432 round-body mini cylinder (double-acting, variable cushion). |
|---|---|
| 16 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSG / DMSG / EMSG sensors. |
MI-family variants: MI / MIC (double acting ±cushion), MSI / MTI (single acting push / pull), MID / MICD (double rod ±cushion), MIJ / MICJ (adjustable stroke ±cushion). Back covers CA / U / R / CM. Mounting LB / FA / SDB / TC.
Where the Airtac MIC Cushioned Mini Cylinder MIC16X100SCM Is Used
Light-Part Ejection
Shoots small plastic or stamped parts out of a press at high speed, using the adjustable air cushion to prevent the 6 mm rod from slamming the end cap.
Package Diverting
Pushes light cartons off a conveyor belt; the stainless build handles the occasional washdown, while the 100.5 N push force easily moves the payload.
Lab Sample Routing
Indexes sample trays in testing equipment where the ISO 6432 dimensions fit tight spaces and the needle-set cushion ensures quiet, shock-free stops.
Is the Airtac MIC Cushioned Mini Cylinder MIC16X100SCM the Right Cylinder?
If your payload is lighter, the smaller AirTAC mini bore is the MI series bumper-only version, so the MIC16 is the smallest adjustable-cushion option available. Stepping up to the MIC20 raises the 0.5 MPa push force to 157 N if this 100.5 N unit is too light. The needle cushion matters most when the piston is running near the 800 mm/s limit or moving a mass close to the 5.1 kg vertical lift threshold, where it absorbs shock that a fixed bumper cannot.
Because a plain double-acting cylinder drifts when air pressure drops or the valve is centered, add an external rod lock or pilot-operated check valve if the load must hold position. This SKU includes the -S magnet for position sensing, and you can mount it using LB foot, FA flange, SDB pivot-block or TC trunnion hardware.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G)
- ✓ Magnet (-S) for sensors?
- ✓ Back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Use correct back cover (CA/U/R/CM) & mount (LB/FA/SDB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac MIC Cushioned Mini Cylinder MIC16X100SCM FAQ
This 16 mm bore cylinder has an M5×0.8 port and an M6x1.0 male rod thread. It delivers 100.5 N push and 86.4 N pull at 0.5 MPa, 140.7 N push and 120.9 N pull at 0.7 MPa, with a theoretical maximum of 20.5 kgf at 1.0 MPa.
Yes, the -S suffix means it has a built-in magnet for CMSG, DMSG and EMSG switches. The variable air cushion at both ends only decelerates the piston near stroke end to reduce shock; it is not a lock or brake, so you need a pilot check valve to hold a load vertically.
