Airtac MSUR Compact Free Mounting Cylinder MSUR16X5S
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Cylinder MSUR16X5S Technical Details
- Model: MSUR16X5S
- Type: Single-acting spring return cylinder
- Bore size: 16mm (0.63")
- Stroke: 5mm (0.2") micro stroke
- Operating pressure: 0.05-0.9 MPa
- Port size: M5x0.8 dual ports
- Cushion type: Rubber buffer + adjustable cushion screw
- Piston rod thread: M4x0.7 external thread
- Mounting style: Free mountable (no dedicated bracket)
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Seal material: NBR/PU hybrid seals
- Weight: 0.25kg (0.55lbs)
- Dimensions: 62mm(L) × 30mm(W) × 30mm(H)
- Protection rating: IP54 (standard dust/moisture resistance)
Ultra-compact pneumatic cylinder designed for precision short-stroke applications requiring minimal space occupation. Features integrated mounting slots (4x Ø4.5mm holes) for flexible positioning and self-aligning capability. The hardened stainless steel piston rod (HRC 45-50) ensures wear resistance in high-cycle operations.
- PCB component insertion mechanisms
- Medical device actuation (ventilator valves, syringe pumps)
- Precision clamping in micro-machining fixtures
- Label applicator positioning systems
- Semiconductor wafer handling robots
Installation guidance: Maintain 0.5-1mm clearance between cylinder base and mounting surface for thermal expansion. Lubricate through air port with ISO VG32 turbine oil (1-2 drops/1000 cycles) when used in dry gas environments. Avoid side loads exceeding 2N.
| Property | Property Value |
|---|---|
| sku | MSUR16X5S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <5mm> |
