Airtac MSUR Compact Free Mounting Cylinder MSUR20X10B
2. Features four-directional mounting capability for flexible installation;
3. Space-saving gang-mounting design allows multiple cylinder combination;
4. Integrated guide boss ensures precise positioning alignment;
5. Precision-machined bore with hard anodized treatment delivers exceptional wear resistance and longevity;
6. Optional magnetic piston version enables position detection functionality;
7. Pre-machined T-slots on cylinder body facilitate adjustable sensor switch mounting;
8. Patented asymmetrical bidirectional sealing structure with compact profile and integrated lubrication reservoir.
Category: Compact Body Cylinder , Brand: AirTAC , Series: MSUR
AirTAC MSUR Series Compact Free Mount Cylinder MSUR20X10B
- Model: MSUR20X10B
- Bore size: 20mm
- Stroke: 10mm (Customizable 5-100mm)
- Action type: Double-acting
- Mounting style: Free mount (no specific orientation required)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s
- Cushion type: Rubber buffer + adjustable cushioning
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8
- Rod material: Chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR (Nitrile rubber)
- Weight: 0.23kg ±2%
- Dimensions (L×W×H):
- Standard length: 76mm (without rod)
- Body diameter: Φ32mm
- Mounting base: 20×20mm square profile
Ultra-compact cylinder with 360° mounting flexibility, featuring a unique anti-rotation mechanism for precise linear motion. The dual-cushion design reduces end-impact noise to below 75dB. Special rod seal structure maintains ≤0.5mm/s leak rate at 0.5MPa. Compatible with ISO 6432 standards.
- PCB handling robots in electronics assembly
- Precision clamping fixtures for CNC machining
- Medical device actuation systems
- Food packaging vertical lift mechanisms
- Automated test equipment positioners
Installation tips:
Apply thread lock on mounting screws (recommended torque 1.2N·m).
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3mm minimum clearance between rod end and load.
| Property | Property Value |
|---|---|
| sku | MSUR20X10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
