Airtac MUR Compact Free Mount Cylinder MUR12X10B
$22.76
Regular price
$30.26
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MUR12X10B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
Installation guidelines:
Use C-shaped mounting brackets (sold separately) for secure fixation.
Lubricate with ISO VG32 turbine oil if operating below 0℃.
Maintain 0.5mm minimum clearance between rod end and load.
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR Series Compact Cylinder MUR12X10B Technical Specifications
- Model: MUR12X10B (Basic Type)
- Bore size: 12mm (ISO 6432 standard)
- Stroke length: 10mm (±0.5mm tolerance)
- Action type: Double-acting
- Mounting style: Front flange (ISO 15552 compatible)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Cushioning type: Rubber buffer (both ends)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Port thread: M5×0.8 (Rc1/8 adapter optional)
- Piston speed: 50–700 mm/s (lubricated)
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel SUS304
- Seals: NBR (standard), optional FKM
- Weight: 0.23 kg (bare cylinder)
- Dimensions:
- Total length: 62mm (stroke 10mm)
- Body diameter: Φ24mm
- Mounting flange: 30×20mm (L×W)
- Rod end thread: M4×0.7
- Protection class: IP40 (dust protected)
Ultra-compact pneumatic cylinder designed for space-constrained automation systems. Features anti-rotation mechanism for precise linear motion control. The through-hole piston rod design allows multi-directional mounting (horizontal/vertical/ceiling). Maintenance-free operation with integrated wear-resistant guide bushings.
Typical Applications:
- PCB handling robots in electronics assembly
- Medical device sample positioning stages
- Packaging machine clamping mechanisms
- Semiconductor wafer transfer systems
- Automated door locking actuators
Installation guidelines:
Use C-shaped mounting brackets (sold separately) for secure fixation.
Lubricate with ISO VG32 turbine oil if operating below 0℃.
Maintain 0.5mm minimum clearance between rod end and load.
Critical notes:
- Requires 40μm filtered air with 1-10mg/m³ oil mist
- Max lateral load: 2.5N at piston rod end
- Not suitable for high shock/vibration environments
| Property | Property Value |
|---|---|
| sku | MUR12X10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
