Airtac MUR Compact Free Mount Cylinder MUR12X40B
2. Four-directional mounting options with tool-free assembly for simplified installation;
3. Modular design allows multi-cylinder parallel mounting, providing space-efficient solutions;
4. Integrated guide boss at front end ensures precise alignment and positioning stability;
5. Precision-honed bore with hard anodizing treatment delivers exceptional wear resistance and extended service life;
6. Optional magnetic piston version enables position sensing functionality;
7. Pre-machined sensor groove facilitates flexible installation of inductive proximity switches;
8. Asymmetric bidirectional sealing structure with compact dimensions and integrated oil reservoir chamber
Category: Compact Free Mount Cylinders , Brand: AIRTAC , Series: MUR
AirTAC MUR12X40B Compact Free Mounting Cylinder Specifications
- Model: MUR12X40B (Standard type with magnetic piston)
- Type: Single-acting spring return (SASR) cylinder
- Bore size: 12mm (ISO 6432 standard)
- Stroke: 40mm (adjustable cushioning ±5mm)
- Mounting style: Free installation (no dedicated bracket required)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃ (NBR seals)
- Cushioning: Elastic buffer + adjustable end cushion
- Port size: M5×0.8 (Rc1/8 adaptor optional)
- Seal material: Nitrile Butadiene Rubber (NBR)
- Protection rating: IP54 (standard wiper design)
- Piston speed: 50–750 mm/s (lubricated condition)
- Weight: 0.22 kg (without accessories)
- Dimensions: 100mm(L) × 28mm(W) × 28mm(H) (retracted position)
Ultra-compact cylinder featuring dual-axis mounting grooves (3mm width) for direct attachment to machinery. The anodized aluminum construction with chrome-plated piston rod resists corrosion in humid environments. Integrated magnet (grade N35) enables position sensing compatibility with most industrial sensors. Spring return force: 2.3N at 0.5MPa.
- PCB handling robots in electronics assembly
- Micro-pneumatic clamping systems
- Laboratory analyzer sample tray positioning
- Cosmetic dispensing valve actuators
- Compact packaging machine stoppers
Operation note:
Lubricate with ISO VG32 turbine oil before initial use.
For vertical mounting, maintain minimum 0.15MPa pressure
to prevent piston drift. Maximum side load: 2.5N.
| Property | Property Value |
|---|---|
| sku | MUR12X40B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <40mm> |
