Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X100-10S
$129.57
Regular price
$137.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X100-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Use locking compound on adjustment screws after alignment. Lubricate through integrated grease nipple (M6×1) every 500,000 cycles with ISO VG32 pneumatic oil. Avoid side impact forces exceeding 10N during operation.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X100-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ12X100-10S
- Type: 3-axis adjustable compact cylinder (rodless type)
- Bore size: 12mm
- Stroke: 100mm (±5mm adjustable range)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Dual-side adjustable flange with T-slot (M4 threaded holes)
- Port size: G1/8 (ISO standard)
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.58kg (including mounting accessories)
- Dimensions: 200mm(L) × 48mm(W) × 42mm(H) (at neutral position)
- Protection rating: IP54 (standard), IP67 optional
- Max lateral load: 15N
- Repeat positioning accuracy: ±0.1mm
A precision multi-axis positioning cylinder featuring micrometer-grade adjustment screws (0.5mm/rotation) on X/Y/Z axes. The anodized surface treatment enhances corrosion resistance, while integrated T-slots enable flexible sensor mounting. Requires dry compressed air with 5-40μm filtration.
Typical Applications:
- PCB component insertion machines
- Semiconductor wafer handling robots
- Optical lens alignment systems
- Precision fixture positioning in CNC tooling
- 3D printing bed calibration mechanisms
Installation note:
Use locking compound on adjustment screws after alignment. Lubricate through integrated grease nipple (M6×1) every 500,000 cycles with ISO VG32 pneumatic oil. Avoid side impact forces exceeding 10N during operation.
| Property | Property Value |
|---|---|
| sku | TCLJ12X100-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 100mm |
