Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X150-30S
$145.38
Regular price
$152.88
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X150-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Use 0.05-0.1Nm torque for adjustment screws. Apply thread-locking compound after final position setting.
Requires weekly lubrication (ISO VG32 oil) through the built-in grease nipple during continuous operation.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X150-30S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ12X150-30S
- Type: Triple-axis adjustable compact cylinder (rodless type)
- Bore size: 12mm
- Stroke: 150mm (adjustable in 0.1mm increments)
- Operating pressure: 0.1-0.9 MPa
- Temperature range: -10℃ to 70℃
- Port size: M5x0.8 (standard) with NPT1/8 adapter option
- Adjustment axes: X/Y/Z (±2mm each axis)
- Mounting type: Front flange with 4xM3 threaded holes
- Piston material: Aluminum alloy with hard anodizing
- Seal material: NBR + PU hybrid seals
- Weight: 580g ±2%
- Dimensions: 168mm(L) × 42mm(W) × 42mm(H)
- Position repeatability: ±0.05mm
- Max lateral load: 15N
- Cushioning: Rubber buffer + adjustable shock absorber
- Protection rating: IP54 (standard), IP67 optional
Precision triple-axis cylinder featuring micrometer-style adjustment screws (0.1mm/division) for ultra-fine positional calibration. The through-shaft design enables bi-directional force transmission, while the aluminum nitride coating ensures smooth operation in low-lubrication environments. Includes integrated T-slot for sensor mounting and anti-rotation guide mechanism.
Typical Applications:
- PCB component insertion machines (Z-axis fine alignment)
- Lens polishing equipment requiring micron-level position tuning
- Semiconductor wafer handling robots
- Precision fixture alignment in coordinate measuring machines
- 3D printer nozzle calibration systems
Installation note:
Use 0.05-0.1Nm torque for adjustment screws. Apply thread-locking compound after final position setting.
Requires weekly lubrication (ISO VG32 oil) through the built-in grease nipple during continuous operation.
| Property | Property Value |
|---|---|
| sku | TCLJ12X150-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | 150mm |
