Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ12X20-10S
$101.19
Regular price
$108.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ12X20-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation protocol:
Use 0.5Nm torque for axis lock screws during calibration.
Requires 5μm filtered air with ISO VG32 lubricator for optimal seal life.
Avoid side-load exceeding 15N during operation.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ12X20-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ12X20-10S
- Type: Triple-axis adjustable compact cylinder (double-acting)
- Bore size: 12mm
- Stroke: 20mm (adjustable via built-in stroke adjusters)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) with optional NPT1/8 adapters
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Mounting style: Side-mount with 4x M3 threaded holes (base plate optional)
- Material: Aluminum alloy barrel, CR-MO piston rod
- Seals: NBR (standard), optional FKM for high temp
- Repeat positioning accuracy: ±0.2mm
- Protection rating: IP54 (standard), IP67 with optional wiper
- Weight: 0.48kg (including all accessories)
- Dimensions:
- Length: 112mm (full extension)
- Width: 42mm (mounting base width)
- Height: 42mm (including adjustment mechanism)
Precision multi-axis positioning cylinder featuring micrometer-style X/Y/Z adjustments (±2mm per axis) for sub-millimeter alignment. Integrated lock nuts maintain position stability under 0.6MPa vibration environments. Anodized surface treatment resists chemical corrosion in industrial settings.
Industrial Applications:
- PCB component insertion machines
- Lens polishing equipment position fine-tuning
- Automated optical inspection (AOI) systems
- Semiconductor wafer handling robots
- Medical device assembly stations
Installation protocol:
Use 0.5Nm torque for axis lock screws during calibration.
Requires 5μm filtered air with ISO VG32 lubricator for optimal seal life.
Avoid side-load exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | TCLJ12X20-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
