Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X10-10S
$108.63
Regular price
$116.13
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X10-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation protocol:
Use 2Nm torque for mounting bolts. Lubricate with ISO VG32 hydraulic oil before initial use.
Perform axis alignment verification after every 50,000 cycles. Avoid side-load exceeding 10% of maximum thrust.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X10-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X10-10S
- Type: 3-axis adjustable compact cylinder (triple adjustment)
- Bore size: Ø16mm
- Stroke: 10mm (adjustable)
- Adjustment range: ±5° in X/Y/Z axes
- Mounting style: Through-hole (M6x1.0 thread)
- Operating pressure: 0.05–0.7 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable pneumatic cushion
- Port size: M5×0.8 (dual ports)
- Material: Aluminum alloy body, NBR seals
- Weight: 480g ±2%
- Dimensions: 85mm(L) × 50mm(W) × 50mm(H)
- Rod end: M6 internal thread
- Repeat positioning accuracy: ±0.2mm
- Max lateral load: 15N
Precision multi-axis positioning cylinder with micrometer-style adjustment screws (0.1mm/rotation resolution). Features integrated locking mechanism with anti-vibration design for stable micro-positioning. Includes wear-resistant guide bushings and double-sealed piston for maintenance-free operation.
Typical Applications:
- PCB component insertion machines
- Lens alignment in optical manufacturing
- Semiconductor wafer handling robots
- Precision fixture positioning systems
- Automated inspection equipment calibration
Installation protocol:
Use 2Nm torque for mounting bolts. Lubricate with ISO VG32 hydraulic oil before initial use.
Perform axis alignment verification after every 50,000 cycles. Avoid side-load exceeding 10% of maximum thrust.
| Property | Property Value |
|---|---|
| sku | TCLJ16X10-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
