Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X100-20S
$145.13
Regular price
$152.63
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X100-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Always perform axis zero-calibration before first use. Maintain 0.5mm minimum clearance between adjustment screws and adjacent components. Lubricate guide shafts every 500,000 cycles.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X100-20S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X100-20S
- Type: 3-axis adjustable cylinder with multi-position locking
- Bore size: 16mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -10℃ to 70℃
- Cushion type: Rubber buffer + adjustable stopper
- Port size: M5x0.8 (dual ports)
- Adjustable stroke range: ±2mm per axis (total 4mm compensation)
- Repeat positioning accuracy: ±0.1mm
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Mounting orientation: Any direction
- Protection rating: IP54
- Weight: 680g ±5%
- Dimensions: 155mm(L) × 42mm(W) × 42mm(H)
Precision 3-axis alignment cylinder with micron-level adjustment capability. Features dual locking screws for X/Y/Z axis compensation, ideal for fine position correction in automated assembly. Anti-rotation design maintains orientation during multi-directional movements. Requires 5μm filtered air supply with ISO VG32 lubricant.
Typical Applications:
- PCB component insertion machines
- Lens module alignment in camera production
- Precision jig calibration systems
- Robotic arm end-effector positioning
- Semiconductor wafer handling equipment
Installation note:
Always perform axis zero-calibration before first use. Maintain 0.5mm minimum clearance between adjustment screws and adjacent components. Lubricate guide shafts every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | TCLJ16X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 100mm |
