Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X200-30S
$117.68
Regular price
$125.18
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X200-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation note:
Use alignment jig (AJS-16) during mounting to ensure parallel installation.
Max lateral load: 15N. Adjust cushion screws before operation - turn clockwise
to decrease cushioning effect. Requires 5μm filtered air.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X200-30S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X200-30S
- Type: 3-axis adjustable cylinder (pneumatic)
- Bore size: 16mm
- Stroke: 200mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable air cushion
- Mounting style: Through-hole base mounting
- Port size: M5x0.8 (G1/8 adapter optional)
- Adjustable axes: X/Y/Z (±2° angular adjustment each)
- Body material: Aluminum alloy (anodized)
- Seal material: NBR + Polyurethane
- Weight: 0.85kg (without accessories)
- Dimensions: 298mm(L) × 40mm(W) × 40mm(H)
- Protection rating: IP40 (standard)
- Lubrication: Pre-lubricated (use ISO VG32 oil if needed)
Precision multi-axis alignment cylinder featuring micrometer-style adjustment screws (0.1mm graduation) for fine positioning. Integrated locking nuts maintain position stability under vibration. Dual piston design with wear-resistant guide bushings ensures smooth multi-directional movement.
Typical Applications:
- Semiconductor wafer handling robots
- Optical lens alignment systems
- PCB drilling machine positioning
- Automated inspection jigs
- 3D printer nozzle calibration
Installation note:
Use alignment jig (AJS-16) during mounting to ensure parallel installation.
Max lateral load: 15N. Adjust cushion screws before operation - turn clockwise
to decrease cushioning effect. Requires 5μm filtered air.
| Property | Property Value |
|---|---|
| sku | TCLJ16X200-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <200mm> |
