Airtac TCLJ Three-Axis Adjustable Cylinder TCLJ16X25-10S
$110.96
Regular price
$118.46
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCLJ16X25-10S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
Installation tip:
Lock adjustment screws with 0.3-0.5Nm torque after alignment.
Use thread-locking adhesive on mounting bolts. Perform axis-by-axis
calibration starting from Z-axis. Lubricate with ISO VG32 hydraulic oil
during maintenance.
2. Dual guide rods manufactured from specialized bearing steel, guided by either linear bearings (ball-type) or bronze bushings, delivering exceptional torsion resistance and lateral load capacity. ★Note: Ball-type linear bearings: Ideal for lifting applications requiring high precision, superior load capacity, and low-friction movement. Bronze sliding bushings: Optimized for braking operations with radial loads, offering 2X greater lateral impact resistance and enhanced torsional rigidity compared to conventional brake cylinders.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while maintaining minimal spatial requirements. Optional air inlet ports enable flexible installation.
4. Precision-engineered positioning holes on base surface, rear end face, and mounting plate (PA holes and XX holes in outline diagram) ensure accurate alignment for high-precision applications.
5. Four sensor grooves on body accommodate multiple sensor mounting configurations.
6. Proprietary structural design supports versatile mounting configurations across multiple orientations.
Category: Adjustable Cylinder | Brand: AIRTAC | Series: TCLJ
AirTAC TCLJ16X25-10S 3-Axis Adjustable Cylinder Specifications
- Model: TCLJ16X25-10S
- Type: 3-axis adjustable compact cylinder (X/Y/Z manual adjustment)
- Bore size: 16mm
- Stroke: 25mm (±2mm adjustable)
- Operating pressure: 0.15–0.8 MPa
- Port thread: M5×0.8 (dual Rc1/8 optional)
- Piston speed: 50–800 mm/s
- Temperature range: -20℃ to 80℃
- Seal material: NBR + Special polyurethane
- Mounting type: Square base with 4×M4 threaded holes
- Adjustment range: ±5° angular compensation (all axes)
- Repeat positioning accuracy: ±0.2mm
- Buffer type: Adjustable rubber cushion
- Weight: 0.38kg (without accessories)
- Dimensions: 196mm(L) × 52mm(W) × 52mm(H)
- Rod end thread: M6×1.0
- Protection rating: IP54 (standard)
Precision multi-axis alignment cylinder with micron-level adjustment capability through three orthogonal adjusting screws (0.5mm pitch). Features integrated anti-rotation guide and wear-resistant chromium-plated rod. Compatible with vacuum environments when paired with optional seals.
Typical Applications:
- Robotic end-effector position fine-tuning
- Semiconductor wafer handling systems
- Optical lens alignment in inspection machines
- Precision stamping die positioning
- 3D printing platform calibration mechanisms
Installation tip:
Lock adjustment screws with 0.3-0.5Nm torque after alignment.
Use thread-locking adhesive on mounting bolts. Perform axis-by-axis
calibration starting from Z-axis. Lubricate with ISO VG32 hydraulic oil
during maintenance.
| Property | Property Value |
|---|---|
| sku | TCLJ16X25-10S |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | <25 mm> |
