Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation protocol:
Requires torque-controlled tightening (1.2N·m max) on adjustment screws.
Perform axis alignment verification using dial indicator after installation.
Recommended 0.3-0.5MPa initial break-in pressure for first 50 cycles.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X100-20S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ16X100-20S
- Type: 3-axis adjustable compact cylinder (rodless type)
- Bore size: 16mm
- Stroke: 100mm
- Operating pressure: 0.15–0.8 MPa
- Mounting style: Front flange (MF1) with 4x M5 threaded holes
- Axes of adjustment: X/Y/Z (±2mm each axis)
- Cushioning: Adjustable pneumatic cushion
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.8kg (excluding accessories)
- Dimensions: 260mm(L) × 40mm(W) × 40mm(H) (full extension)
- Accessories: Includes 4x M5×16 mounting bolts and alignment shims
- Protection rating: IP40 (standard), IP67 optional
- Lubrication: Pre-lubricated (Use ISO VG32 hydraulic oil)
Precision triple-axis adjustable cylinder with micrometer-style fine-tuning collars (20S suffix indicates 0.02mm adjustment resolution). Features dual piston guides for enhanced moment resistance and anti-rotation stability. The TCMJ series incorporates a unique wedge-lock mechanism that maintains position without creeping during vibration.
Typical Applications:
- Semiconductor wafer handling robots
- Optical lens alignment systems
- PCB drilling machine Z-axis compensation
- Automated inspection fixture positioning
- Packaging machine gripper centering
Installation protocol:
Requires torque-controlled tightening (1.2N·m max) on adjustment screws.
Perform axis alignment verification using dial indicator after installation.
Recommended 0.3-0.5MPa initial break-in pressure for first 50 cycles.
Maintenance:
Relubricate every 500km of cumulative travel.
Avoid silicone-based lubricants.
Adjustment collars require annual backlash inspection.
| Property | Property Value |
|---|---|
| sku | TCMJ16X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 100mm |
