Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ16X125-20S
$104.18
Regular price
$111.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ16X125-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation note:
Use vibration-resistant thread locker on adjustment screws.
Requires 5-10μm filtered air with dew point -20℃ below ambient.
Avoid side loads exceeding 15N. Alignment tolerance ±0.5mm/m.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X125-20S 3-Axis Adjustable Cylinder Specifications
- Model: TCMJ16X125-20S
- Type: 3-axis adjustable compact cylinder (rodless type)
- Bore size: 16mm
- Stroke length: 125mm ±0.5mm
- Adjustment range: X/Y/Z axes ±2° (20S suffix indicates 20mm stroke for fine adjustment mechanism)
- Operating pressure: 0.1–0.9 MPa
- Medium: Clean dry air (ISO 8573-1:2010 Class 3.4.2)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Mounting type: 4x M5 threaded holes (base mounting)
- Cushioning: Rubber buffer + adjustable end lock
- Material: Aluminum alloy body, CR-SUS piston rod
- Weight: 1.25kg ±3% (without accessories)
- Dimensions: 186mm(L) × 44mm(W) × 44mm(H) (extended position)
- Port size: M5x0.8 (dual ports on both ends)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (Relubrication interval: 3,000km stroke)
Precision multi-axis positioning cylinder with integrated micro-adjustment mechanism (20mm secondary stroke). Features triple-axis angular compensation (±2° in all directions) and zero-point locking capability. The dual-port design enables bidirectional pressure control for force-sensitive applications. Mirror-finished rod surface reduces seal wear.
Typical Applications:
- Semiconductor wafer handling robots
- Optical lens alignment systems
- PCB assembly positioning stages
- Automotive door panel riveting machines
- Packaging line product orientation correction
Installation note:
Use vibration-resistant thread locker on adjustment screws.
Requires 5-10μm filtered air with dew point -20℃ below ambient.
Avoid side loads exceeding 15N. Alignment tolerance ±0.5mm/m.
| Property | Property Value |
|---|---|
| sku | TCMJ16X125-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 125mm |
