Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ16X60-20S
$93.95
Regular price
$101.45
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ16X60-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation protocol:
Apply M3×0.5 mounting screws with 1.2N·m torque. Perform axis alignment
before locking adjustment screws. Lubricate sliding surfaces with ISO VG32
hydraulic oil during maintenance cycles. Minimum 20mm clearance required
for adjustment tool access.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ16X60-20S 3-Axis Adjustable Cylinder Technical Details
- Model: TCMJ16X60-20S
- Type: 3-axis adjustable pneumatic cylinder (X/Y/Z adjustment)
- Bore size: Ø16mm
- Stroke: 60mm
- Operating pressure: 0.05–0.9 MPa
- Medium: Clean air (ISO 8573-1:2010 Class 3.4.3)
- Ambient temperature: -10℃ to 80℃
- Adjustment range: ±2mm (axial), ±5° (angular)
- Mounting type: 20mm square base (ISO 6432 compatible)
- Piston rod material: Hard chrome-plated steel
- Seal material: NBR with wear-resistant ring
- Cushioning: Adjustable rubber buffer
- Weight: 580g ±3%
- Dimensions:
- Length (extended): 135mm
- Width (body): 50mm
- Height (with adjustment): 72mm
- Base plate: 20×20mm
Precision triple-axis adjustable cylinder featuring micrometer-style fine-tuning mechanism (0.1mm graduation) for complex alignment tasks. The integrated lock nuts maintain positional stability under vibration. Compatible with ISO 6432 mounting accessories and equipped with anti-rotation guide for Z-axis movement.
Industrial Applications:
- PCB assembly machine nozzle alignment
- Robotic end-effector position calibration
- Optical lens positioning systems
- Automated test equipment fixturing
- Packaging machine tooling adjustment
Installation protocol:
Apply M3×0.5 mounting screws with 1.2N·m torque. Perform axis alignment
before locking adjustment screws. Lubricate sliding surfaces with ISO VG32
hydraulic oil during maintenance cycles. Minimum 20mm clearance required
for adjustment tool access.
| Property | Property Value |
|---|---|
| sku | TCMJ16X60-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 16mm |
| Stroke | 60mm |
