Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ20X100-20S
$114.88
Regular price
$122.38
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ20X100-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation protocol:
Always lock adjustment screws with 0.3-0.5N·m torque after alignment.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.5mm minimum clearance between cylinder body and adjacent components.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ20X100-20S 3-Axis Adjustable Cylinder Technical Details
- Model: TCMJ20X100-20S
- Type: 3-axis adjustable cylinder (double-acting)
- Bore size: Ø20mm
- Stroke: 100mm (±5mm adjustable range)
- Operating pressure: 0.05–0.9 MPa
- Operating temperature: -10℃ to 80℃
- Cushioning: Rubber buffer + adjustable screw
- Mounting style: MSQB20 square base with 4×M5 threaded holes
- Port size: M5×0.8 (G1/8 adapter optional)
- Adjustment axes: X/Y/Z (±2° angular compensation)
- Rod material: Chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Weight: 2.8kg (including all adjustment components)
- Dimensions: 240mm(L) × 80mm(W) × 60mm(H) (max extended length)
- Positioning repeatability: ±0.2mm
- Max lateral load: 15N at full extension
- ISO standard: 15552 (compliant)
Triple-axis compensator cylinder with micro-adjustment screws (0.5mm/rotation) for precision alignment in multi-axis systems. Features dual-layer wiper seals and corrosion-resistant rod treatment. Integrated mounting grooves allow direct sensor installation. Requires 5μm filtered air with ISO 8573-1:2010 [4:4:3] class.
Industrial Applications:
- PCB board handling robots requiring positional compensation
- Precision fixture alignment in CNC machining centers
- Conveyor belt tracking adjustment systems
- Glass panel polishing equipment with Z-axis pressure control
- Automated optical inspection (AOI) positioning stages
Installation protocol:
Always lock adjustment screws with 0.3-0.5N·m torque after alignment.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.5mm minimum clearance between cylinder body and adjacent components.
| Property | Property Value |
|---|---|
| sku | TCMJ20X100-20S |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
