Airtac TCMJ Three-Axis Adjustable Cylinder TCMJ20X100-50S
$114.88
Regular price
$122.38
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
TCMJ20X100-50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JIS standards;
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
Installation tip:
Use locknuts on adjustment screws after final positioning. Lubricate with ISO VG32 hydraulic oil
before initial operation. Max lateral load: 15N at full extension.
2. Dual guide rods manufactured from specialized bearing steel, guided by linear ball bearings or bronze sliding bearings, delivering exceptional resistance to torsion and lateral loads.★Note: Linear ball bearings: Ideal for lifting applications requiring high precision, heavy load capacity, and low-friction movement. Bronze sliding bearings: Specially engineered for radial load applications like braking systems, offering over twice the lateral impact resistance of standard brake cylinders with enhanced torsional rigidity.
3. Integrated design combines driving unit and guiding mechanism within a single body, eliminating additional accessories while providing compact dimensions and adjustable intake ports for flexible installation;
4. Precision positioning holes on base surface, rear end face, and mounting plate (refer to PA holes and XX marked holes in outline drawing) ensure high-accuracy alignment for critical applications;
5. Four sensor grooves on body enable multiple sensor mounting configurations;
6. Proprietary body structure supports multi-orientation mounting solutions;
Category: Adjustable Cylinders | Brand: AIRTAC | Series: TCMJ
AirTAC TCMJ20X100-50S Three-Axis Adjustable Cylinder Specifications
- Model: TCMJ20X100-50S
- Type: Three-axis adjustable cylinder (with multi-directional mounting)
- Bore size: 20mm
- Stroke: 100mm
- Mounting spacing: 50mm (center-to-center)
- Port size: G1/8 (M5 optional)
- Operating pressure: 0.05–0.8 MPa
- Adjustable stroke range: ±5mm (total 10mm adjustment capacity)
- Operating temperature: -20℃ to 80℃
- Cushion type: Adjustable elastic cushion
- Mounting style: Side-mounted bracket with 4x M5 threaded holes
- Material: Aluminum alloy cylinder tube, hardened stainless steel piston rod
- Weight: 1.8kg (with standard accessories)
- Dimensions: 200mm(L) × 50mm(W) × 70mm(H) (at neutral adjustment position)
- Rod end thread: M10×1.25
- Protection rating: IP54 (standard seals)
Precision three-axis cylinder featuring ±5mm stroke adjustment via three orthogonal set screws (X/Y/Z axes). Includes anti-rotation mechanism for stable load handling. Chrome-plated piston rod with wear-resistant seals (NBR standard, optional FKM for high temp). Optimized for applications requiring micro-positioning compensation.
Typical Applications:
- Automated alignment systems in PCB assembly
- Semiconductor wafer handling robots
- Precision fixturing for CNC machine tooling
- Automotive component testing jigs
- Packaging line product positioning gates
Installation tip:
Use locknuts on adjustment screws after final positioning. Lubricate with ISO VG32 hydraulic oil
before initial operation. Max lateral load: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | TCMJ20X100-50S |
| Adjustable Stroke | <50mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
