Airtac X-KAPT Pneumatic-Hydraulic Intensifier X-KAPT6301000101TS
AirTAC X-KAPT6301000101TS Pneumatic-Hydraulic Intensifier Cylinder Specifications
- Model: X-KAPT6301000101TS
- Type: Two-stage gas-liquid combined intensifier
- Amplification ratio: 10:1 (adjustable via pressure regulator)
- Air pressure input: 0.2–0.8 MPa
- Hydraulic output: 2–8 MPa (oil pressure)
- Stroke: 40mm total (30mm pneumatic + 10mm hydraulic)
- Bore size: 63mm (main cylinder)
- Operating medium: Clean air (ISO 8573-1) & ISO VG68 hydraulic oil
- Temperature range: -20℃ to 80℃
- Weight: 5.8kg ±2% (with standard fittings)
- Dimensions: 210mm(L) × 115mm(W) × 115mm(H)
- Seal material: NBR/PU composite
- Port size: G1/4 (air in/out), M14×1.5 (hydraulic port)
- Cycle rate: ≤60 cycles/min (dependent on oil viscosity)
- Return spring force: 450N (pre-loaded)
Hybrid intensifier combining pneumatic efficiency with hydraulic precision, featuring oil-filled damping for shock-free operation. The dual-stage design achieves 85% energy efficiency through pressure-balance optimization. Built-in oil reservoir with visual level indicator prevents cavitation. Requires 5μm filtered air supply and annual oil replacement.
- Precision press-fitting of automotive bearings
- Battery cell compression in EV manufacturing
- Sheet metal embossing with controlled tonnage
- Plastic injection mold clamping assistance
- High-force microspot welding electrodes
Installation protocol:
Mount vertically with ±3° tolerance. Allow 30-minute oil settling period after
horizontal transportation. Use anti-vibration pads when installed on moving machinery.
| Property | Property Value |
|---|---|
| sku | X-KAPT6301000101TS |
