Airtac X-KAPT Pneumatic-Hydraulic Intensifier X-KAPT6301000103TF
AirTAC X-KAPT Pneumatic-Hydraulic Intensifier Cylinder X-KAPT6301000103TF Specifications
- Model: X-KAPT6301000103TF
- Type: Two-stage gas-liquid combined intensifier
- Working medium: Compressed air (drive side) / Hydraulic oil (output side)
- Maximum air pressure: 8 bar (116 psi)
- Boost ratio: 6:1 (adjustable via pressure regulation)
- Stroke length: 100mm (precise stroke control ±0.5mm)
- Port sizes: G1/4" (air inlet), M16x1.5 (hydraulic output)
- Maximum output force: 6,300kg (13,889 lbf)
- Operating temperature: -10℃ to 60℃ (14℉ to 140℉)
- Cycle rate: 30-60 cycles/min (oil-dependent)
- Hydraulic capacity: 110cc ISO VG68 oil
- Weight: 18.7kg (41.2 lbs)
- Dimensions: 430mm(L) × 180mm(W) × 250mm(H)
- Seal materials: HNBR/NBR with wear-resistant guide rings
- Mounting orientation: Vertical (±5° tolerance)
High-force compact intensifier combining pneumatic efficiency with hydraulic precision. Features pressure maintenance function during dwell time and overload protection through hydraulic compensation. The dual-seal design prevents oil-air mixing, with integrated shock absorbers for smooth stroke completion. Requires 40μm filtered air and periodic oil level checks.
- Sheet metal stamping/punching machines
- Automotive part riveting systems
- Bearing press-fit assembly lines
- Plastic injection molding clamping units
- Forging equipment auxiliary power
Operation tip:
Maintain oil temperature below 50℃ using cooler in high-cycle applications.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil. Install with
50mm clearance around cylinder for heat dissipation.
| Property | Property Value |
|---|---|
| sku | X-KAPT6301000103TF |
