Airtac X-KAPT Pneumatic-Hydraulic Intensifier X-KAPT6301000103TS
AirTAC X-KAPT6301000103TS Pneumatic-Hydraulic Intensifier Cylinder Specifications
- Model: X-KAPT6301000103TS
- Type: 3-stage gas-liquid combined intensifier
- Bore Size: 63mm (pneumatic side) / 50mm (hydraulic side)
- Stroke Length: 100mm (pre-stroke) + 10mm (boost stroke)
- Max. Air Pressure: 8 bar (116 psi)
- Boost Ratio: 10:1 (outputs up to 80 bar hydraulic pressure)
- Oil Capacity: 300±20ml (ISO VG 68 recommended)
- Port Size: G1/4 (air inlet) / M16×1.5 (hydraulic output)
- Operating Temperature: 5℃ to 60℃ (with anti-freeze option available)
- Cushioning: Adjustable pneumatic cushion at both ends
- Material: Aluminum alloy body, chrome-plated piston rod
- Weight: 5.8kg (12.8 lbs)
- Dimensions: 340mm(L) × 130mm(W) × 160mm(H)
- Protection Class: IP54 (standard), IP67 optional
Multi-stage hybrid cylinder combining pneumatic speed with hydraulic force precision. Features integrated oil reservoir and automatic pressure maintenance system. The dual-sensor ready design (magnetic switches not included) enables precise position feedback. Anti-rotation guide structure ensures stable output during high-force applications.
- Precision metal stamping (battery contacts, jewelry forming)
- Composite material compression molding
- High-torque fastener installation (aerospace assemblies)
- Plastic injection molding machine clamping
- Automotive brake pad press systems
Installation note:
Requires vertical mounting (±15° tolerance). Maintain 1.5× bore size clearance
behind cylinder for maintenance access. Use shock absorber when cycle rate
exceeds 30 times/minute. Pre-lubricate for initial 500,000 cycles.
- Max thrust force: 19,600N (at 8 bar input)
- Air consumption: 45NL/min @ 6 bar
- Return spring force: ≥250N
- Replacement seal kit: AK6301-SK
| Property | Property Value |
|---|---|
| sku | X-KAPT6301000103TS |
