Airtac X-KAPT Pneumatic-Hydraulic Intensifier X-KAPT6301000151TF
AirTAC X-KAPT6301000151TF Hydro-Pneumatic Intensifier Cylinder Specifications
- Model: X-KAPT6301000151TF
- Type: 3-stage air-oil intensifier with return spring
- Bore size: Ø63mm (main cylinder)
- Stroke: 100mm (air piston) + 15mm (oil intensification)
- Max. air pressure: 8 bar (116 psi)
- Output oil pressure: Up to 160 bar (2320 psi)
- Force ratio: 20:1 (standard model)
- Operating medium: Filtered air (40μm) + ISO VG68 hydraulic oil
- Temperature range: -10℃ to 60℃ (non-freezing conditions)
- Port size: G1/4 (air inlet), M14×1.5 (hydraulic port)
- Body material: Aluminum alloy (hard anodized)
- Rod material: Chrome-plated steel
- Seal type: Polyurethane/NBR compound seals
- Weight: 6.8 kg (dry, without oil filling)
- Dimensions: 380mm(L) × 125mm(W) × 165mm(H)
- Mounting orientation: Vertical (±5° tolerance)
- Preload stroke: 15mm (adjustable via external stopper)
High-efficiency hybrid cylinder combining pneumatic speed with hydraulic force precision. Features dual-pressure operation: rapid approach (low pressure air) followed by high-force pressing (hydraulic intensification). Integrated oil reservoir with sight glass and automatic compensation system prevents cavitation. Requires 5-7 bar dry air supply with <40μm filtration.
- Precision metal stamping (connector pins, jewelry forming)
- Bearing press-fitting in automotive assembly lines
- Battery cell compression testing equipment
- Plastic injection mold clamping assistance
- Electronic component riveting (SMT machine integration)
Maintenance note:
Check oil level monthly through sight glass (maintain between 80-90% full).
Bleed air from oil chamber after 50,000 cycles or 6 months of operation.
Use only specified anti-foaming hydraulic oil.
| Property | Property Value |
|---|---|
| sku | X-KAPT6301000151TF |
