Airtac 2-Way Solenoid Valve 2W050-10-C
2. Direct-acting normally closed 2-way 2-position solenoid valve featuring fast and precise switching;
3. Compact design with minimized footprint, lightweight construction, and tool-free installation;
4. Brass valve body with B-class thermal-rated coil. Standard FPM/FKM seals ensure compatibility with diverse media. Custom seal materials available upon technical consultation;
5. IP65-rated coil protection, available in lead wire or DIN connector configurations.
Category: Solenoid Valves | Brand: AIRTAC | Series: 2W
AirTAC 2W050-10-C Solenoid Valve Technical Details
- Model: 2W050-10-C
- Type: 2-position 2-way normally closed (direct acting)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Weight: 320g ±5% (including coil)
- Dimensions: 60mm(L) × 25mm(W) × 45mm(H)
- Seal material: NBR (Nitrile), optional FKM (Fluorocarbon)
- Temperature range: -5℃ to 80℃ (no freezing)
- Power consumption: 1.6W (DC), 3.2VA (AC)
- Protection rating: IP65 (coil assembly)
- Response time: ≤15ms (at 0.5MPa)
- Max flow rate: 450 NL/min (ANR, at 0.5MPa)
High-cycle solenoid valve with brass body and manual override, featuring dust-tight construction for industrial environments. The zero differential pressure operation capability makes it suitable for vacuum applications. Requires 5μm filtered compressed air with ISO 8573-1:2010 Class 3.2.4 air quality.
- Pneumatic cylinder control in assembly lines
- Vacuum generator switching in packaging systems
- Medical gas control panels
- Textile machinery air flow management
- Semiconductor manufacturing equipment
- Automatic door locking systems
Installation guidelines:
Mount with 10mm clearance for heat dissipation. Use flexible tubing to
prevent vibration transfer. Lubricate with ISO VG32 turbine oil if used
in high-cycle applications (>500,000 operations/month).
| Property | Property Value |
|---|---|
| sku | 2W050-10-C |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC 110V |
