Airtac 2KL Solenoid Valve 2KL03008EI
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL03008EI Solenoid Valve Specifications
- Model: 2KL03008EI
- Type: 5/3-way double solenoid, center closed (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 520g ±5% (with connectors)
- Dimensions: 76mm(L) × 54mm(W) × 67mm(H)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -10℃ to 80℃ (with anti-freeze measures below 0℃)
- Power consumption: ≤2.8W (DC), ≤5VA (AC)
- Flow rate: 1200Nl/min (at 0.5MPa)
- Response time: ≤25ms (exhaust to actuation)
- Protection rating: IP67 (dustproof and temporary immersion protection)
- Port thread depth: 12mm (minimum engagement length)
High-flow proportional control valve with center blocking function, featuring dual manual overrides and LED status indicators. The hardened aluminum body with electroless nickel plating ensures durability in humid environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3 air quality (max 5mg/m³ oil content).
- Pneumatic cylinder sequencing in assembly lines
- Clamping/unclamping mechanisms in CNC machining centers
- Vacuum cup control systems for material handling
- Automated packaging machinery with position hold requirements
- Cleanroom equipment requiring IP67 protection
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain minimum 15mm clearance below valve for condensate drainage.
Use thread sealant on port connections (PTFE tape not recommended).
Critical note:
Always install downstream pressure regulators. Direct connection to
air receivers exceeding 1.0MPa will void warranty. Cycle rate
should not exceed 5Hz continuous operation.
| Property | Property Value |
|---|---|
| sku | 2KL03008EI |
| Port Size | PT1/4 |
| Flow Aperture | <3mm> |
| Coil Voltage | AC24V |
