Airtac 2KL Solenoid Valve 2KL05010FI
2. Piston pilot normally open 2-way, 2-position solenoid valve with fast response and high flow capacity;
3. Wide pressure range adaptability, offering High Pressure (H) type and Standard type variants;
4. Compact structure with small footprint, lightweight design, and tool-free maintenance;
5. SUS304 stainless steel body construction, H-class heat-resistant coil, and PTFE (Teflon®) seals ensuring compatibility with multiple media, especially optimized for high-temperature water and saturated steam applications;
6. IP65-rated coil protection, available with direct lead wire or DIN connector electrical interfaces.
Category: Fluid Solenoid Valves | Brand: Airtac | Series: 2KL
AirTAC 2KL05010FI 5/2-Way Solenoid Valve Specifications
- Model: 2KL05010FI
- Type: 5/2-way double solenoid (pilot-operated)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5% (with coil)
- Dimensions: 58mm(L) × 34mm(W) × 67mm(H)
- Body material: Anodized aluminum alloy
- Seal material: Heat-resistant NBR (Nitrile)
- Temperature range: -5℃ to 80℃ (with peak tolerance to 120℃ for ≤30min)
- Flow coefficient (Cv): 1.3
- Response time: ≤15ms (at 0.5MPa)
- Protection rating: IP67 (coil), IP40 (valve body)
- Electrical connection: DIN43650 Form A connector
- Service life: ≥10 million cycles (under rated conditions)
High-speed 5-port solenoid valve optimized for bidirectional cylinder control, featuring dual manual override and surge suppression. The hardened aluminum construction ensures vibration resistance in industrial environments. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.2.4 air quality. Includes LED status indicator and reverse polarity protection.
- Robotic arm gripper position control
- CNC machine tool clamping systems
- Plastic injection molding ejectors
- Automated assembly line actuators
- Textile machinery tension control
- Bottle capping machine sequencing
Installation protocol:
Mount in vibration-damped orientation with 20mm clearance for heat dissipation.
Use copper-free lubricants if required. Cycle testing recommended before continuous
operation - energize coils for ≤5 minutes during initial commissioning.
| Property | Property Value |
|---|---|
| sku | 2KL05010FI |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | DC12V |
