Airtac 4HV Manual Rotary Valve 4HV210-06
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV210-06 Manual Rotary Valve Technical Details
- Model: 4HV210-06
- Type: 4/2-way manual rotary valve (spring return)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure range: 0.2–0.8 MPa (29–116 psi)
- Max flow rate: 750 L/min (Cv=1.3)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Body material: Anodized aluminum alloy
- Handle torque: ≤1.5 N·m
- Mounting: Panel mount with 32mm DIN slot
- Weight: 215g ±5g (including handle)
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Port thread depth: 10mm engagement
- Cycle life: ≥500,000 operations
Robust manual override valve featuring a chrome-plated steel rotary handle with positive tactile feedback. The dual-bearing design ensures smooth 90° rotation for precise flow path selection. Includes integrated mounting flanges and tamper-resistant detent mechanism. Compatible with ISO 15407-1 standards.
- Emergency override in automated production lines
- Manual control of clamping fixtures in CNC machinery
- Air circuit configuration in pneumatic training stations
- Maintenance bypass in compressed air systems
- Process testing setups requiring manual intervention
- Handle detent force adjustable via side-mounted hex screw
- Optional lockout plate available (Accessory Code: 4HV-LP06)
- Compatible with vacuum applications (0.04 MPa minimum)
| Property | Property Value |
|---|---|
| sku | 4HV210-06 |
| Position | 4-way 2-position |
| Port Size | PT1/8 |
