Airtac 4HV Manual Rotary Valve 4HV210-08
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV210-08 Manual Rotary Valve Specifications
- Model: 4HV210-08
- Type: 3-position (L-type) detented manual rotary valve
- Port configuration: 5 ports (P, A, B, R1, R2)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Operating temperature: -20℃ to 80℃ (no freeze)
- Valve body material: Aluminum alloy (anodized surface)
- Seal material: HNBR (hydrogenated nitrile) for high temperature resistance
- Actuation torque: ≤0.5 N·m
- Weight: 320g ±5g
- Dimensions: 78mm(L) × 34mm(W) × 54mm(H)
- Mounting: Direct panel mounting with M5 screws
- Position indication: Colored rotational indicator with click-stop feedback
- Protection rating: IP40 (dust protected)
Industrial-grade manual directional control valve featuring positive center position lock and tactile position feedback. The 135° rotation arc enables quick switching between "A-side exhaust", "Closed center", and "B-side exhaust" modes. Hard chrome-plated spool ensures smooth operation even after 500,000+ cycles.
- Emergency override in automated production lines
- Manual mode selection for hydraulic test benches
- Safety exhaust control in plastic injection molding machines
- Mobile equipment pneumatic circuit isolation
- Laboratory pressure regulation systems
Operation guidance: Apply firm clockwise rotation until audible click confirms position engagement. Lubricate spindle quarterly with ISO VG32 hydraulic oil. Avoid side-loading the handle during operation.
- Mounting bracket kit 4HV-MB2
- Extended handle 4HV-EH8 (150mm length)
- Position lock pin set 4HV-PLP
| Property | Property Value |
|---|---|
| sku | 4HV210-08 |
| Position | 4-way 2-position |
| Port Size | PT1/4 |
