Airtac 4HV Manual Rotary Valve 4HV21006L
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV21006L Manual Rotary Valve Specifications
- Model: 4HV21006L
- Type: 3-position manual rotary valve (Lockable)
- Port size: PT1/4 (G1/4 equivalent)
- Operating pressure: 0.05–1.0 MPa
- Flow capacity: 850 L/min (ANR)
- Actuation torque: ≤1.5 N·m
- Weight: 320g ±5g
- Dimensions: 54mm(L) × 54mm(W) × 76mm(H)
- Body material: Anodized aluminum alloy
- Seal material: HNBR rubber (high nitrile)
- Temperature range: -20℃ to 80℃
- Port thread standard: ISO 228/1 (BSPP)
- Position indication: Tactile detent with visual arrow marker
Robust manual override valve featuring a three-position (center closed) rotary mechanism with positive locking capability. The ergonomic knob provides 180° rotation with 45° per position, designed for precise flow control in high-vibration environments. Features dual O-ring seals and anti-corrosion treatment for humid conditions.
- Emergency shutdown systems in pneumatic circuits
- Production line manual override stations
- Hydraulic system pilot pressure control
- Test bench flow regulation
- Mobile machinery manual control panels
Installation note:
Apply thread sealant to port connections (not included).
For vertical mounting, ensure exhaust ports face downward to prevent debris accumulation.
Lubricate rotating mechanism with ISO VG32 hydraulic oil annually.
| Property | Property Value |
|---|---|
| sku | 4HV21006L |
| Position | 4-way 2-position |
| Port Size | PT1/8 |
