Airtac 4HV Manual Rotary Valve 4HV230-06-S-L
2、Large effective flow area ensures minimal pressure loss;
3、Dual installation options (panel mount with included nuts or bottom mount) for flexible configuration.
Category: Manual Rotary Valves | Brand: Airtac | Series: 4HV
AirTAC 4HV230-06-S-L Manual Rotary Valve Specifications
- Model: 4HV230-06-S-L
- Type: 4-port 3-position manual rotary valve (detented operation)
- Port configuration: P (pressure), A/B (actuator ports), R/S (exhausts)
- Port size: G1/4 (BSPP) female threads
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 1,200 NL/min (ANR)
- Operating temperature: -20℃ to 80℃ (NBR seals)
- Weight: 320g ±5%
- Dimensions: 78mm(L) × 42mm(W) × 68mm(H)
- Body material: Anodized aluminum alloy
- Spindle type: Stainless steel shaft with nylon handle
- Seal compatibility: Compatible with non-lubricated air (optional oil mist)
- Mounting: Panel mount with M5 threaded holes (4x)
- Torque requirement: ≤0.5 N·m for position switching
Industrial-grade manual directional control valve featuring tactile position feedback through 60° rotation increments. The chrome-plated spindle ensures smooth operation even under vibration, with triple O-ring sealing for leak-free performance. Designed for systems requiring manual override or permanent manual control.
- Emergency stop circuits in automated machinery
- Pneumatic training equipment and educational setups
- Manual mode selection in packaging line diverters
- Air circuit configuration in prototype development
- Maintenance bypass systems for hydraulic/pneumatic hybrids
Installation note:
Apply thread sealant on port connections (do not over-tighten - max 15 N·m).
For vertical mounting, position exhaust ports downward to prevent debris accumulation.
Lubricate spindle quarterly with silicone grease (ISO VG 1 grade).
| Property | Property Value |
|---|---|
| sku | 4HV230-06-S-L |
| Position | 4-way, 3-position |
| Port Size | PT1/8 |
