Airtac 4M Solenoid Valve 4M120-06-A
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M120-06-A 5/2-Way Solenoid Valve Technical Details
- Model: 4M120-06-A
- Type: 5/2-way double pilot operated (monostable)
- Port size: PT1/4 (G1/8 optional)
- Thread standard: ISO228/ISO6149 compatible
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 1200 NL/min (at 0.5 MPa)
- Voltage options: DC12V, DC24V, AC110V(50/60Hz), AC220V(50/60Hz)
- Power consumption: ≤2.2W (DC) / ≤3.5VA (AC)
- Response time: ≤20ms (excitation), ≤15ms (de-excitation)
- Seal material: Heat-resistant NBR (up to 80℃ intermittent)
- Temperature range: -20℃ to 70℃ (continuous operation)
- Protection rating: IP67 (coil), IP40 (valve body)
- Porting pattern: ISO 5599-1 standard
- Weight: 450g ±5% (with coil)
- Dimensions: 85mm(L) × 40mm(W) × 60mm(H)
High-flow solenoid valve with double pilot operation for precise directional control in pneumatic systems. Features corrosion-resistant aluminum alloy body with hard anodized treatment and electromagnetic shielding design. The "4M" series utilizes a unique low-friction spool structure achieving over 50 million cycles lifespan. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Automated assembly line cylinder control
- Food packaging machine actuators
- Plastic injection molding machine clamping units
- Textile machinery air circuit switching
- Automotive welding fixture positioning
Installation guidelines:
Mount horizontally with coil facing upward. Maintain minimum 30mm clearance around valve for heat dissipation. Use flexible tubing to prevent vibration transmission. Perform monthly manual override testing for critical systems.
| Property | Property Value |
|---|---|
| sku | 4M120-06-A |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
