Airtac 4M Solenoid Valve 4M21006AI
2、Sliding spool structure with excellent sealing performance and rapid response characteristics;
3、Dual-coil bistable function for position memory retention in 4M series 5/2-way valves;
4、Precision-bored cylinders with specialized surface treatment ensure low friction, minimum operating pressure (0.15MPa), and extended service life;
5、Maintenance-free operation requiring no lubrication;
6、Side port mounting configuration enables direct coupling with actuators;
7、Integrated manual override for simplified commissioning and maintenance;
8、Multiple standard voltage options available for global compatibility.
Category: Solenoid Valves, Brand: AIRTAC, Series: 4M
AirTAC 4M21006AI Solenoid Valve Technical Details
- Model: 4M21006AI
- Valve type: 5/2-way double solenoid (pilot-operated)
- Port configuration: 1/4" (PT1/4 BSPP thread)
- Effective area ratio: 1:1.2 (for low pressure operation)
- Operating pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Response time: ≤25ms (energize), ≤35ms (de-energize)
- Flow rate: 850 NL/min (Cv=1.3 at 0.5MPa)
- Seal material: High-grade HNBR (Hydrogenated Nitrile)
- Ambient temperature: -5℃ to 80℃ (with anti-freeze measures below 0℃)
- Protection class: IP67 (dust-tight & protected against temporary immersion)
- Weight: 215g ±5g (excluding connector)
- Dimensions: 46mm(W) × 34mm(H) × 76mm(L)
- Port thread depth: 9.5mm (minimum engagement depth)
High-performance 5/2-way valve with dual coil configuration, featuring precision-machined stainless steel spool and wear-resistant seals. Designed for bidirectional cylinder control requiring position hold functionality. The aluminum alloy body includes oxidation-resistant coating for harsh environments. Requires 5μm filtration (40μm max particle size) with lubricated air (ISO VG32 equivalent).
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- CNC tool changers with position feedback systems
- Food processing equipment (FDA-compliant versions available)
- Battery production line pneumatic actuators
Installation requirements:
Maintain ≤3° deviation from horizontal mounting plane. Use flexible tubing
(≥300mm length) for vibration isolation. Apply 24V surge protection
for DC models in high-EMI environments.
| Property | Property Value |
|---|---|
| sku | 4M21006AI |
| Position | 5 Ports 2 Position |
| Port Size | PT1/8 |
| Standard Voltage | AC220V |
