Airtac 4V Coil Terminal 4V110-016-4A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V110-016-4A Coil Terminal Specifications
- Model: 4V110-016-4A
- Coil type: DIN43650 Form A (standard square flange)
- Voltage rating: 24VDC ±10% (custom options: 12VDC/110VAC/220VAC)
- Current draw: 0.8A @24VDC (instantaneous power: 19.2W)
- Resistance: 30Ω ±10% @20℃
- Insulation class: Class F (155℃)
- Temperature range: -20℃ to +120℃ (ambient)
- Protection rating: IP67 (dust/water resistant)
- Lead wire: 200mm PVC cable (UL2651 22AWG)
- Terminal connection: Quick-connect tab (6.3mm width)
- Core tube material: Stainless steel SUS304
- Coil housing: PBT thermoplastic (UL94 V-0 flame rating)
- Weight: 52g ±3g
- Dimensions: 32mm(L) × 21.5mm(W) × 15.2mm(H)
- Certifications: CE, RoHS, REACH compliant
High-performance solenoid coil with optimized magnetic circuit design, featuring 20% higher pull-in force than standard models. The epoxy-encapsulated winding ensures vibration resistance up to 10G acceleration. Compatible with 4V210/4V310 series valves. Includes built-in surge protection diode for DC versions.
- High-cycle pneumatic valve actuation systems
- Plastic injection molding machine controls
- Automated assembly line clamping devices
- Industrial dishwasher valve clusters
- CNC machine tool pneumatic circuits
Installation note:
Ensure valve core alignment within ±0.5mm during mounting. For continuous operation above 60℃,
derate voltage by 3% per 10℃ increment. Use torque ≤0.4N·m when tightening mounting screws.
| Property | Property Value |
|---|---|
| sku | 4V110-016-4A |
