Airtac 4V Coil Terminal 4V110-016-8A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V110-016-8A Coil Terminal Specifications
- Model: 4V110-016-8A
- Type: Direct-acting solenoid valve with DIN43650A coil connector
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage tolerance: ±10% of rated voltage
- Voltage options:
- DC12V (2.5W)
- DC24V (2.8W)
- AC110V (4.5VA)
- AC220V (4.8VA)
- Weight: 180g ±5g (coil assembly only)
- Dimensions: 55mm(L) × 35mm(W) × 75mm(H)
- Seal material: Temperature-resistant HNBR (-20℃ to 150℃)
- Ambient temperature range: -20℃ to 70℃ (non-freezing)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection rating: IP65 (coil)/IP40 (valve body)
- Insulation class: Class F (155℃)
- Duty cycle: 100% continuous operation
High-performance solenoid coil featuring dual-chamber epoxy encapsulation for enhanced moisture resistance. The 4V110-016-8A utilizes a UL-certified copper winding with thermal overload protection, designed for industrial environments with electrical interference. Compatible with ISO 4400 standard mounting patterns.
- High-cycle pneumatic presses (1M+ operations/year)
- Plastic injection molding machine valve stacks
- Food processing equipment with washdown requirements
- Battery production line vacuum systems
- Semiconductor manufacturing gas control
Installation note:
Use M4×12 stainless steel screws with 0.6-0.8Nm torque for mounting.
Maintain ≥25mm clearance from high-frequency power sources.
For AC coils, install surge suppressor (R-C circuit) when switching >100k cycles/day.
| Property | Property Value |
|---|---|
| sku | 4V110-016-8A |
