Airtac 4V Coil Terminal 4V110-017-8A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V110-017-8A Coil Terminal Specifications
- Model: 4V110-017-8A
- Type: DIN-type plug-in coil (24VDC)
- Voltage rating: DC24V ±10%
- Power consumption: 2.8W (Class F insulation)
- Current draw: 117mA @ 24VDC
- Protection class: IP65 (dust-tight & water jet resistant)
- Temperature range: -30℃ to +100℃ (with intermittent operation up to 130℃)
- Coil inductance: 0.65H ±10%
- Lead wire length: 200mm (7.87") with UL2651 22AWG wires
- Connector type: 2-pin M8 male quick-disconnect
- Core tube material: Stainless steel SUS304
- Weight: 85g ±3g
- Dimensions: 22mm(W) × 36mm(H) × 45mm(L)
- Certifications: CE, RoHS, REACH compliant
High-efficiency solenoid coil with overcurrent protection design, featuring a dual-sealed epoxy encapsulation process that prevents moisture ingress in humid environments. The optimized magnetic circuit structure ensures stable actuation force across temperature variations (-30℃~100℃). Includes built-in varistor for voltage spike suppression.
- Retrofitting older 4V series valves with upgraded coils
- High-cycle automation equipment (≥1 million operations)
- Food processing machinery requiring washdown protection
- Plastic injection molding machine valve stacks
- Battery-powered systems needing low current draw
Installation note:
Ensure 0.5mm minimum clearance between coil and valve body during mounting.
Use torque-limited driver (0.6-0.8N·m) for terminal screw connections.
Avoid bending wires within 15mm of coil housing.
| Property | Property Value |
|---|---|
| sku | 4V110-017-8A |
