Airtac 4V Coil Terminal 4V210-016-2A
Category: Solenoid Valve Coils | Brand: AIRTAC | Series: 4V
Engineered for industrial automation systems, AIRTAC 4V solenoid valve coils feature UL-certified insulation with F/H-class temperature ratings (155°C/180°C). Compatible with 24V DC to 220V AC voltages, these coils integrate moisture-resistant epoxy resin encapsulation and IP65 protection for harsh environments. The DIN-compliant design ensures secure mounting with integrated DIN43650 connectors, while built-in surge suppression diodes enhance electrical stability. Optimized electromagnetic efficiency delivers <3W power consumption with ±10% voltage tolerance. Includes LED operation indicators and maintenance-free construction for pneumatic valve actuation in ISO 5599-1 applications.
AirTAC 4V210-016-2A Coil Terminal Specifications
- Model: 4V210-016-2A
- Type: 5/2-way monostable solenoid valve (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure range: 0.15–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155℃)
- Maximum flow rate: 850 l/min (ANR)
- Weight: 420g ±5% (including coil and connector)
- Dimensions: 58mm(L) × 48mm(W) × 85mm(H) (excluding fittings)
- Body material: Die-cast aluminum alloy (anodized finish)
- Seal material: HNBR rubber (high nitrile for oil resistance)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: DC: 2.5W, AC: 4.5VA
- Response time: ≤30ms (excitation), ≤50ms (de-excitation)
- Protection rating: IP67 (coil)/IP40 (valve body)
- Manual override: Built-in emergency manual operator
- Electrical connection: DIN43650 Form A connector
High-flow directional control valve with optimized magnetic circuit design for stable actuation under variable pressure. Features anti-vibration structure and surge protection circuitry. The dual-chamber design minimizes internal leakage (<0.1 l/min at 0.5MPa). Requires ISO 8573-1 class 3 compressed air with lubricant injection capability.
- Pneumatic cylinder sequencing in assembly lines
- Clamping mechanisms for CNC machinery
- Material handling systems with frequent cycling
- Plastic injection molding air circuits
- Food processing equipment (requires oil-mist lubrication)
Installation guidelines:
Mount in vibration-damped orientation (max 5G shock resistance).
Maintain 0.5m minimum distance from high-frequency inverters.
Use M3.5 screws with 0.6-0.8Nm torque for mounting.
Perform monthly manual cycling for maintenance.
| Property | Property Value |
|---|---|
| sku | 4V210-016-2A |
