Airtac 6V-F Base 6V100M15F
$30.46
Regular price
$37.96
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
6V100M15F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enables modular integration of directional control valves from the same series into valve banks, achieving space optimization and cost efficiency;
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
Installation note:
Apply thread sealant (LOCTITE 5452 recommended) on port connections.
Use torque wrench for even pressure distribution during manifold assembly.
Maximum lateral bending force ≤50N.
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Bracket 6V100M15F Technical Specifications
- Model: 6V100M15F
- Type: Modular valve manifold base (6V-F series)
- Material: Anodized aluminum alloy (A6063-T5)
- Compatible Valves: 4V-M5/M7/10C series solenoid valves
- Mounting Pitch: 15mm (ISO 4400 standard)
- Port Size: G1/8 (BSPP thread)
- Max Operating Pressure: 1.0 MPa
- Temperature Range: -5℃ to 80℃
- Weight: 0.68 kg ±2%
- Dimensions: 100mm(L) × 38mm(W) × 28mm(H)
- Surface Hardness: HV 12±2 (anodized layer)
- Seal Type: Integrated NBR gasket (replaceable)
- Mounting Torque: 1.2-1.5 N·m (for M5 screws)
Precision-machined modular base for multi-valve manifolds, featuring leak-proof design with staggered flow channels. The T-slot structure allows flexible expansion and supports up to 6 valve positions. Includes built-in silencer pockets and auto-drain grooves.
Typical Applications:
- Centralized pneumatic control stations
- Robotic end-effector tooling systems
- Beverage filling line valve clusters
- Semiconductor wafer handling equipment
- Textile machinery air distribution
Installation note:
Apply thread sealant (LOCTITE 5452 recommended) on port connections.
Use torque wrench for even pressure distribution during manifold assembly.
Maximum lateral bending force ≤50N.
| Property | Property Value |
|---|---|
| sku | 6V100M15F |
