Airtac 6V-F Base 6V100M17F
2. Centralized inlet/exhaust ports and unified wiring harness routing ensure simplified troubleshooting and maintenance accessibility;
3. Modular design with high expandability allows flexible combinations and future expansions of connected directional control valve quantities;
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: 6V-F
AirTAC 6V-F Series Base Bracket 6V100M17F Technical Details
- Model: 6V100M17F
- Series: 6V-F Modular Mounting Base
- Material: Aluminum alloy (anodized black)
- Mounting Hole Pattern: 100mm center spacing (ISO 15407-1 compliant)
- Compatible Valves: 6V210/6V310 series solenoid valves
- Port Configuration: 1/4" NPT (G1/8 optional)
- Seal Material: NBR (FKM available for high-temp variants)
- Pressure Rating: 0.05-1.0 MPa (operating), 1.5 MPa burst
- Temperature Range: -20℃ to 80℃ (continuous duty)
- Surface Finish: Hard anodized (HV400 hardness)
- Weight: 0.82 kg ±2%
- Dimensions: 100mm(L) × 40mm(W) × 25mm(H)
- Mounting Torque: 1.2-1.5 N·m (M5 screws)
- Vibration Resistance: ≤10-55Hz, 1.5mm amplitude
Precision-machined modular base for multi-valve manifolding, featuring leak-proof design with redundant sealing channels. The T-slot structure enables flexible combination with up to 10 valves in series. Integrated pressure relief grooves prevent cross-port contamination during rapid cycling.
- Centralized pneumatic control panels
- Automated assembly line valve clusters
- Robotic end-effector manifold systems
- Plastic injection molding machine manifolds
- CNC tool changer pneumatic circuits
Installation protocol:
Clean mounting surface with IPA before assembly. Use spiral-wrap thread sealant on ports.
Tighten diagonally in 3 stages (30% → 70% → 100% torque) to ensure even compression.
| Property | Property Value |
|---|---|
| sku | 6V100M17F |
