Airtac 6V Solenoid Valve 6V0510J04A050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510J04A050 Solenoid Valve Specifications
- Model: 6V0510J04A050
- Type: 5/2-way single solenoid (spring return)
- Port size: PT1/8 (G1/8 optional)
- Effective area ratio: 20% (pilot-operated design)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Proof pressure: 1.2 MPa
- Voltage tolerance: ±10% (Standard: DC24V, AC110V/50-60Hz, AC220V/50-60Hz)
- Power consumption: 1.8W (DC), 3.5VA (AC)
- Response time: ≤15ms (at 0.5MPa)
- Ambient temperature: -5℃ to 60℃ (no freeze)
- Port thread depth: 10mm (minimum engagement)
- Seal material: HNBR (Hydrogenated Nitrile)
- Body material: Die-cast aluminum alloy (anodized)
- Protection rating: IP67 (dustproof/water immersion resistant)
- Weight: 280g ±5% (with coil)
- Dimensions: 55mm(L) × 44mm(W) × 78mm(H) (excluding connectors)
- Port orientation: ISO 5599-1 standard (interchangeable)
- Flow capacity: 750 l/min (ANR, at 0.5MPa)
- Expected lifespan: 50 million cycles (at rated conditions)
High-flow 5/2 directional control valve with optimized spool geometry for reduced pressure drop. Features dual-chamber sealing technology and gold-plated connectors for reliable performance in humid environments. Requires 5μm filtered lubricated air (ISO 8573-1 class 4). Compatible with modular valve manifolds via side-mounting grooves.
- Pneumatic clamping systems in CNC machinery
- Automated assembly line actuators
- Plastic injection molding ejectors
- Textile machinery cylinder control
- Food processing pneumatic circuits (oil-mist lubricated)
Installation protocol:
Mount with M4 screws (2.5Nm torque limit). Maintain ≥15mm clearance
below valve for exhaust airflow. Perform monthly manual cycling
during standby periods to prevent spool sticking.
| Property | Property Value |
|---|---|
| sku | 6V0510J04A050 |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
