Airtac 6V Solenoid Valve 6V0510J04A200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510J04A200 Solenoid Valve Specifications
- Model: 6V0510J04A200
- Type: 5/2-way single solenoid spring return (monostable)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 215g ±5g (with coil)
- Dimensions: 60mm(L) × 40mm(W) × 65mm(H)
- Seal material: NBR (standard), FKM available for high-temp
- Temperature range: -5℃ to 60℃ (NBR), -5℃ to 80℃ (FKM)
- Flow coefficient (Cv): 1.2
- Response time: ≤15ms (on/off)
- Protection rating: IP65 (coil), IP40 (valve body)
- Cycle life: ≥10 million cycles
- Manual override: Built-in push-button
- Porting pattern: ISO 5599-1 compliant
High-flow 5/2-way valve with precision-machined stainless steel spool for reliable switching in industrial environments. Features dust-tight metal sleeve construction and surge-protected coil. Requires 5μm filtered air with max 1% oil content. Compatible with vacuum applications when paired with EPDM seals (optional).
- Pneumatic cylinder control in assembly lines
- Clamping mechanisms in CNC machinery
- Material handling systems with dual-acting actuators
- Textile machinery air circuit switching
- Semiconductor manufacturing equipment
Installation note:
Mount in vibration-free position using M4 mounting screws (not included).
Maintain minimum 5mm clearance below valve for condensate drainage.
Use flexible tubing to prevent mechanical stress on ports.
Critical: Do NOT use silicone-based lubricants - compatible with
ISO VG32 hydraulic oil only. Maximum allowable leakage:
20 cm³/min at 0.5 MPa.
| Property | Property Value |
|---|---|
| sku | 6V0510J04A200 |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
