Airtac 6V Solenoid Valve 6V0510J04B050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510J04B050 Solenoid Valve Specifications
- Model: 6V0510J04B050
- Type: 5/2-way single solenoid control (spring return)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage options: DC24V (±10%), AC220V (±10% 50/60Hz)
- Flow coefficient (Cv): 1.2
- Response time: ≤20ms (energized), ≤30ms (de-energized)
- Weight: 280g ±5g
- Dimensions: 56mm(L) × 45mm(W) × 25mm(H)
- Valve body material: Anodized aluminum alloy
- Seal material: FKM (Fluorocarbon Rubber)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Power consumption: 2.5W (DC24V), 4.5VA (AC220V)
- Protection rating: IP67 (dust-tight, temporary immersion)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with reinforced coil insulation (Class F) for industrial durability. Features dual-color LED status indicator (red/green) and surge protection circuitry. Compatible with ISO 15407-1 standards, designed for bi-directional pneumatic systems requiring rapid cycling (up to 5Hz). Requires 5μm filtered lubricated air (ISO 8573-1:2010 Class 3.4.2).
- Automated assembly line actuators
- Plastic injection molding machine ejectors
- CNC tool changers with position feedback
- Food processing pneumatic grippers (FDA-compliant variants available)
- Lithium battery production dry room environments
Installation protocol:
Install with vibration-damping mounts in high-cycle applications.
Maintain ≥15mm clearance from adjacent components for heat dissipation.
Use copper-free anti-seize compound on threads in marine environments.
| Property | Property Value |
|---|---|
| sku | 6V0510J04B050 |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
