Airtac 6V Solenoid Valve 6V0510J04B200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510J04B200 Solenoid Valve Technical Details
- Model code breakdown: 6V (Series) 05 (Port Size) 10 (Function) J04 (Voltage/Construction) B200 (Special Configuration)
- Valve type: 5/2-way double pilot operated (bi-stable)
- Port thread: PT1/4 (G1/4 optional)
- Effective sectional area: 18mm²
- Operating pressure range: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: DC: 2.5W / AC: 3.2VA
- Maximum flow rate: 650 L/min (ANR)
- Seal material: Heat-resistant NBR (Nitrile) -40℃ to 120℃ version available
- Ambient temperature: -5℃ to 80℃ (no freeze)
- Response time: ≤20ms (with rated voltage)
- Protection class: IP67 (dustproof & temporary immersion)
- Weight: 280g ±5% (without connector)
- Dimensions: 72mm(L) × 42mm(W) × 65mm(H)
- Port alignment: ISO 5599-1 standard (compliant with multiple manifold systems)
- Flow coefficient (Cv): 0.18
High-flow bistable valve with dual coil latching mechanism requiring only pulse signals for state changes. Features low-hysteresis seals and anti-vibration design for mobile hydraulic/pneumatic hybrid systems. Includes manual override and position-indication LED (optional). Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Plastic injection molding machine clamp control
- Automated assembly line cylinder sequencing
- Textile machinery air circuit switching
- Battery production vacuum/pressure systems
- Food processing dual-pressure regulation
Installation criticals:
Mount horizontally with coil axis vertical. Maintain minimum 15mm clearance
from adjacent components. Use copper-free anti-seize compound on threads.
Requires surge protection module for AC coils in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | 6V0510J04B200 |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
