Airtac 6V Solenoid Valve 6V0510J04C050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510J04C050 Solenoid Valve Specifications
- Model: 6V0510J04C050
- Type: 5-port, 2-position (5/2-way) with double solenoid operation
- Port size: PT1/8 (G1/8 optional)
- Operating pressure range: 0.1–0.9 MPa
- Voltage variants: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5g (including connectors)
- Dimensions: 68mm(L) × 45mm(W) × 92mm(H)
- Seal material: Heat-resistant FKM fluorocarbon rubber
- Temperature tolerance: -10℃ to 80℃ (with 5℃ safety margin)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤25ms (energize), ≤15ms (de-energize)
- Flow capacity: 850 l/min (ANR) at 0.5 MPa
- Protection class: IP67 (dustproof & temporary immersion protection)
- Port thread depth: 10mm (minimum engagement required)
High-flow directional control valve featuring dual-coil latching design for bistable operation. The brass body with hard-anodized aluminum cover ensures corrosion resistance in humid environments. Integrated surge suppression protects coils from voltage spikes. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Pneumatic press clamping/unclamping systems
- Automated assembly line cylinder sequencing
- Textile machinery pattern control
- Battery manufacturing process automation
- Plastic injection molding ejector systems
Installation guidelines:
Mount with vibration-damping brackets in high-shock environments.
Maintain 15mm clearance above valve for heat dissipation.
Always use copper-free anti-seize compound on port threads.
| Property | Property Value |
|---|---|
| sku | 6V0510J04C050 |
| Port Size | PT 1/2 |
| Standard Voltage | AC 110V |
