Airtac 6V Solenoid Valve 6V0510J04C200
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510J04C20 Solenoid Valve Technical Specifications
- Model: 6V0510J04C200
- Series: 6V compact modular valve
- Valve type: 5/2-way, double solenoid (dual coil)
- Port size: PT1/4 (G1/4 equivalent)
- Effective area: 10mm² (critical flow path)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage specification: DC24V ±10% (DIN EN 175301-803 Form C)
- Coil power: 1.6W (class F insulation)
- Response time: ≤25ms (pressurized at 0.5MPa)
- Weight: 380g ±5% (including manifold base)
- Dimensions: 54mm(L) × 40mm(W) × 72mm(H)
- Seal material: Heat-resistant HNBR (-20℃ to 120℃)
- Ambient temperature: -5℃ to 60℃ (non-freezing)
- Flow rate: 650 NL/min (ANR, ΔP=0.1MPa)
- Protection rating: IP67 (dustproof/immersion-resistant)
- Manual override: Built-in emergency pushbutton
- Mounting: ISO 5599-1 compliant sub-base
High-density 5-port pneumatic valve with dual independent coils for bi-stable control. Features anti-vibration terminals and surge protection diodes. Optimized spool geometry reduces pressure drop by 18% compared to previous generation. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Robotic end-effector tool changers
- CNC machine clamp sequencing
- Bottle filling station actuators
- Automated conveyor diverters
- Plastic injection molding ejectors
Operational guidance:
Maintain coil voltage within ±10% tolerance. For vertical installation,
use manifold bracket support (AMT-06 accessory recommended).
Cycle rate should not exceed 5Hz continuously.
| Property | Property Value |
|---|---|
| sku | 6V0510J04C200 |
| Port Size | PT 1/2 |
| Standard Voltage | AC 110V |
