Airtac 6V Solenoid Valve 6V0510J04F050
2、Internal venting structure collects pilot air for centralized exhaust through R/S ports;
3、High-pressure die-cast aluminum alloy body features precision-machined inner bore for optimized flow path geometry and enhanced flow capacity;
4、Available in threaded and quick-insertion port types, compatible with base-mounted valve manifolds for space-efficient installation.
Category: Solenoid Valves | Brand: AIRTC | Series: 6V
AirTAC 6V0510J04F050 Solenoid Valve Specifications
- Model: 6V0510J04F050
- Type: 5/2-way single solenoid with spring return
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Flow capacity: 850 l/min (Cv=1.2)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 480g ±5% (without connector)
- Dimensions: 96mm(L) × 45mm(W) × 70mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (with intermittent operation up to 120℃)
- Power consumption: 2.8W (DC24V), 4.5VA (AC)
- Protection rating: IP67 (dustproof and waterproof)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤0.02 MPa
High-flow directional control valve with rapid response, featuring copper-free aluminum alloy body for corrosion resistance. Optimized spool design reduces internal leakage to <50 ml/min under maximum pressure. Includes manual override and surge suppression for industrial durability. Requires ISO 8573-1:2010 Class 3 compressed air (max 5μm particle size).
- Industrial automation: Cylinder control in assembly lines
- Food processing: Pneumatic actuator control with washdown compatibility
- Material handling: Vacuum cup systems
- Textile machinery: Air jet loom nozzle control
- Semiconductor: Cleanroom equipment with low outgassing
Installation note:
Mount in vibration-free environment using M4 mounting screws (max torque 1.2N·m).
Maintain 15mm clearance below valve for connector access. Lubricate with ISO VG32
turbine oil if used in high-cycle applications (>1 million operations).
| Property | Property Value |
|---|---|
| sku | 6V0510J04F050 |
| Port Size | PT 1/2 |
| Standard Voltage | DC12V |
